OmiPay

Stylish Appearance

State-of-the-art smart mobile POS with complete color touch screen, small and exquisite, easy to carry.

High intelligent

Android OS based to enable rapid development and loading of customized value-added software applications, intelligent interactivity to support seamless payment connected to industry applications.

Full-function

All-in-one smart mobile terminal with innovative multifunction of all card payments, such as NFC , barcode, QR code and sound wave payment. Equipped with QR code reader module on top, and 5 MP camera at the bottom.

Exceptional security

PCI 4.X, EMV, PBOC, Union Pay intelligent POS terminal safety certified; equipped with multiple tamper protection and self-destruction mechanism.

Application Scenarios

1、Merchant enters amount to be charged in an OmiPay point of sale terminal.

2、Merchant selects “confirm”，merchant scans customer’s QR code.

3、System automatically deducts RMB from the customer’s account according to the current exchange rate, payment is complete and terminal prints out a receipt.

Technical indicators

Standard Configuration
OS	Android 5.1 version or above.
CPU	High performance Quad-core processor +Special secure CPU.
Memory	1GB RAM, 8GB Flash
Extendable memory	Support Micro SD card(TF card) up to 32GB.
Display	5.5-inch full color LCD, resolution of 1280*720.
Screen	Capacitive multi-touch screen.
Button	Power switch, volume +/-.
Peripheral port	One Micro USB OTG, compatible with USB2.0 HS standard.
Audio	One loudspeaker, one microphone, support sound recording & media play.
Magnetic card reader	Track 1/2/3, bi-directional, conforming to ISO7811 standard.
Chip card reader	Intelligent chip card reader, conforming to ISO7816, EMV2000/PBOC3.0 standard.
PSAM card reader	One PSAM card slot (max. two), conforming to ISO7816 standard.
RFID card reader	Support ISO/IEC 14443 Type A/B, Mifare® , NFC.
Printer	High-speed thermal printer, max. speed: 90mm/s（18lps） Paper width: 58mm, Paper roll diameter: 40mm.
Wireless communication	Support WCDMA/GPRS
WIFI	802.11b/g/n.
Bluetooth	Bluetooth 2.1~4.0.
Camera	5 Megapixels, auto focus.
Scanner	Optional 1D or 2D barcode reader, support barcode payment.
Battery	DC7.4V/2000mAh Lithium-ion battery.
Power supply	Input: AC100～240V/0.2A, 50/60Hz; Output: DC5.0V/1.0A power adapter.
Docking station	Optional.
Operating environment	Temperature: -10～50°C，relative humidity: 5℅～95℅（non-condensing）.
Storage environment	Temperature: -30~70°C，relative humidity: 5℅～95℅（non-condensing）.
